Outdoor optical cable is an optical cable designed for outdoor environments. It has mechanical properties such as pressure resistance, corrosion resistance, and tensile resistance, and is suitable for various harsh outdoor environments. Its main features include:
1.Mechanical properties : Outdoor optical cables usually have high tensile strength and pressure resistance, thicker protective layers, and are usually armored (i.e. wrapped in metal skin) to cope with harsh external environments.
2.Environmental characteristics : Outdoor optical cables are designed to withstand harsh environments such as wind, sun, cold and humidity, and are waterproof, corrosion-resistant and UV-resistant.
3.Structural characteristics : The structure of outdoor optical cables usually includes two types: central tube type and layer stranded type . The central tube type optical cable, such as GYXTW type optical cable , has a structure including loose tube, reinforcing components and water blocking tape. Layer stranded optical cable adopts "SZ" bidirectional layer stranding technology, which has the characteristics of full-section water blocking and high strength.
Common types
1.Central bundle tube optical cable : such as GYXTW type, suitable for various laying methods such as direct burial and overhead, with excellent waterproof, compression and bending resistance.
2.Stranded optical cable : Adopts "SZ" bidirectional stranded technology, suitable for long-distance communication and inter-office communication, especially for occasions with high requirements for mechanical strength.
3.Heavy armored optical cable : It has loose tube made of high modulus material and metal reinforcement core, suitable for long-distance communication and inter-office communication under harsh environmental conditions .
Application Scenario
Outdoor optical cables are widely used in various communication networks that require high reliability and durability, including interconnection between buildings, remote network connections, etc. It has a wide range of applications and is suitable for direct burial, overhead, pipeline and other laying methods. It is especially suitable for occasions with high requirements for mechanical strength and rodent prevention.
